Design of Mechanical Structure and Hydraulic
System of Automatic Hydraulic Brick Press
Abstract: Full-automatic hydraulic pressure brick machine become essential equipment in industry manufacture especially in chinaware industry. Heavy Full-automatic hydraulic pressure brick machine is easy to be damaged because of absence of strength, stiffness and vibration due to its structure and force. Thus, the analysis and optimization of structure and an important part of Full-automatic hydraulic pressure brick machine designing.
this topic uses the traditional theory method to carry on the design, the computation, the intensity examination to the ZY1200 completely automatic hydraulic pressure wall brick press fuselage structure, used AUTOCAD design software to the main traverse, the foundation, on the portable beam, under the portable beam, the host hydraulic cylinder, the column, the final assembly drawing to carry on the project cartography, in referred to some company to have produced four girders four column hydraulic pressure wall brick hydraulic press hydraulic system which as well as has consulted massively after the hydraulic system design books, determined that the semiautomatic numerical control system's design proposal, has drawn up the hydraulic scheme, has given electrical system's working instructions, and has carried on the feasibility analysis to it, finally to entire the design carries on the system analysis, obtains the entire design to be practical and feasible.
Key word: Automatic hydraulic brick press; Column; Beams.
